Technical Note 04

Explosion Resistant Design of Offshore Structures

FABIG Members: Log-in to access all FABIG resources

SUMMARY

Where gas explosions represent a credible risk, platform topsides have to be designed to withstand explosion loading. There are two aspects to consider: firstly loading on the structure and secondly loading and effect on equipment. This technical note deals principally with the first aspect but is also relevant to the second because the performance of the structure, e.g. deflection and acceleration, affects the equipment mounted on it. It is also relevant to the evaluation of the strength and deformation capacity of the equipment items themselves, e.g. pipes and vessels.

This Technical Note covers both design of new platforms and reassessment of existing structures and is designed to supplement Sections 3.5 and 5.4.4 of the Interim Guidance Notes (IGN's).

Several methodologies are presented: from simple hand methods to complex non-linear finite element analysis (NLFEA) for determining ultimate strength. In practice a mixture of methods will be used on a given installation. For new designs the emphasis will be on the simpler methods but for structural reassessment it will often be necessary to quantify strength reserve and for this more complex methods of analysis may be required.

Non-member price: £150.00 Add to Basket
Published in: 2017
Keywords:
n/a

Online purchase options:

Non-Members of FABIG are able to purchase PDF copies of the FABIG Technical Guidance documents.
